Galvanized steel |
|
|
|
| Home > Galvanized steel> Hot-dip galvanized steel sheet and coil |
|
|
  |
Product Name |
Hot-dip Galvanized Steel Sheet Coils |
Specifications |
JIS G3302 1998 |
SGCC |
SGC340,SGC400,SGC490,SGC570,SGCH |
SGCD1,SGCD2,SGCD3 |
SGHC,SGH340,SGH400,SGH440,SGH490 |
ASTM A653M 2003 |
CS Type A,CS Type B,CS Type C |
FS Type A, FS Type B |
SS GR230, SS GR255,SS GR275,SS GR340,SS GR550 |
DDS,EDDS |
AS 1397 2001 |
G1,G2,G3 |
G250,G300,G350,G450,G550 |
EN10327 2004
/EN10143 1993 |
DX51D,DX52D,DX53D |
EN10326 2004
/EN10143 1993 |
S220GD,S250GD,S280GD,S320GD,S350GD,S550GD |
Steel Thickness (mm) |
0.2-4.5 |
Width (mm) |
600-1550 |
Coating Mass |
JIS G3302 1998 |
Z08,Z12,Z18,Z20,Z22,Z25,Z27,Z35,Z45 |
ASTM A653M |
Z80,Z120,Z180,Z200,Z220,Z250,Z275,Z350,Z450 |
AS 1397 2001 |
Z100,Z200,Z275,Z350,Z450 |
EN10326/7 |
Z100,Z140,Z200,Z225,Z275,Z350,Z450 |
Spangle |
Regular Spangle, Minimized Spangle, Extra-Smooth |
Chemical Surface Treatment |
Chromating Treatment, Oiled or Anti-finger print |
|
Remarks:
- Tolerance for thickness, width, flatness ect, can conform to the individual product specification.
- Coil inside diameters can be either 508mm or 610mm,maximum coil outside diameter is 2000mm.
- Weight of a single coil can be from 3 to 25 metric tons.
- Please make enquires to our Sales& Marketing Division for products with special specifications.
|
|
|
|
|
| |
 |
